Shacman F3000 6X4 Tractor Truck for sale | ||
Max. running speed (km/h) | 95 | |
Drive System | 6×4 | |
Overall Dimensions （L*W*H）(mm) | 6785×2490×3560 | |
Approach / departure angle (°) | 20 / 60 | |
Curb weight (kg) | 8800 | |
01-Total mass (kg) | 25000 | |
Wheel base (mm) | 3175+1400 | |
Overhang (mm) (front/rear) | 1485/725 | |
Track width (mm) (front/rear) | 2011/ 1800 | |
Engine | WP12.430E201 ( Weichai Engine, Euro 2) | |
Horsepower | 430hp | |
Gearbox | 12JSD200T-B (FAST GEAR), manual, 12F & 2R | |
Clutch | Ф 430 Diaphragm type | |
Steering | ZF technology | |
Cab | F3000 cabin with A/C & single sleeper | |
Axle | Front axle | MAN 7.5T |
Rear axle | 13 Ton MAN driving axle , final ratio 4.266 | |
Oil tank(L) | 400L (ALLOY) | |
Tyre（radial tyre） | 12.00R20(10+1 spare tyre) | |
1.Strong power with large output torque, lower engine speed at maximum torque, best power and explosive force in the industry.
2.Equipped with dual intermediate shaft transmission with high reliability, suitable for different working conditions, strong climbing abiity and high fuel economy.
3.The axle adopts the European synchronous FAG low resistance maintenance-free bearing technology witn independent lubrication systemLarge 1000L fuel tank can ensure sufficient fuel and long mileage without refueling.
4.WABCO valves with an added air pressure testing interface allowing easy to measture air pressure, braking performance and troubleshooting.
5.VosS joints allows the vehicle to have greatly improved reliability, better air tightness and better pressure holding capacity.
6.Adopting a new generation of electrical systems such as the advanced CAN bus technology of BOsCH with automatic fault detection.
Shandong Haiming Import and Export Co., Ltd. was established in 2018. It is a manufacturer of large trailers and heavy trucks integrating product design, research and development, production and sales. The factory is located in Shandong Province with a plant area of 30,000 square meters.
The company's products cover plate, low plate, container, warehouse, dump, van and other series of semitrailer, our company and SinotruK, FAW, Shaanxi automobile, Dongfeng and other brands have a deep cooperation relationship, can provide you with dump trucks and tractors. In addition, we are working hard to develop new products to meet different requirements. We have export licenses, and our products are exported to more than 50 countries and regions worldwide, to Central and South America, the Middle East, Central Asia and Africa. The company has gathered strong technical force, has strong market competitiveness and R & D capability, has advanced stamping, welding equipment and modern production process and perfect quality management system. Established and improved from the product pre-sale, sale, after-sales service management system.
